Underfloor Air Distribution
What is UFAD?
Underfloor Air Distribution (UFAD), is an innovative HVAC system that distributes air through floor diffusers and grilles instead of traditional overhead ducts in the ceiling.
This method utilizes the floor plenum beneath raised floors as a pathway for air distribution.
The natural upward airflow promotes a more uniform distribution of air, enhancing temperature consistency throughout space. A unique and fundamental concept of UFAD.
What are the typical elements that contribute to the optimal functioning of UFAD system?
Raised Access Floor
An RAF, essential for UFAD systems, consists of removable panels supported by pedestals, creating an underfloor plenum. This space distributes conditioned air and houses essential UFAD components.
Supply Air Diffusers
Embedded in the raised floor panels, allowing conditioned air to enter the occupied space. Available in constant (CAV) or variable (VAV) volume types as per needs.
Fan Terminal Units
Optional units are located under the floor to boost air distribution in larger spaces or specific zones.
Cables and Accessories
Integration of power and data cables, power modules, thermostats, and plenum pressure controls to enhance system functionality and efficiency.
Air Handling Unit (AHU)
The central unit that conditions (heats, cools, and dehumidifies) the air before it is distributed through the plenum.
Return Air Pathways
Openings or ductwork that allow return air to flow back to the AHU, often located at ceiling level or high on walls.
Supply Air Pathways
Ductwork within the underfloor plenum that ensures additional supply of conditioned air to locations remote to the AHU.
Wall Construction
The design and materials of walls, which impact thermal insulation and airflow within the space.
Temperature zones and Heat Load Calculations
Determining the amount of heating or cooling required to maintain comfort in a space. Critical for designing and sizing the UFAD system to ensure it meets the thermal demands of the building and its occupants efficiently.
- Improved Air Quality: UFAD systems deliver fresh, clean air from below, reducing airborne contaminants and enhancing indoor air quality.
- Higher Energy Efficiency: By utilizing the natural thermal stratification of indoor spaces, UFAD systems minimize energy consumption and contribute to sustainable building practices.
- Thermal Comfort: UFAD systems offer zonal temperature control, allowing occupants to adjust their environment according to individual preferences of comfort and productivity.
- Low Profile Design: UFAD diffusers are discreetly integrated into the flooring, preserving architectural aesthetics, and maximizing usable space.
- Quiet Operation: UFAD systems operate quietly, minimizing noise disruptions in indoor environments.
- High adaptability and Retrofitting – UFAD systems are ideal for a wide range of environments, including offices, educational institutions, and high-occupancy areas like airports and auditoriums. The system is adaptable to changes in building layouts or usage patterns, providing long-term flexibility and value while also making it a smart choice for both new constructions and retrofits.
- Long-Term Cost Savings: While initial installation costs may be comparable or slightly higher than traditional systems, UFAD systems can offer significant long-term savings through reduced energy bills, lower maintenance costs, and extended equipment lifespan.
- Optimized Floor to Ceiling Height: The implementation of a UFAD system in greenfield sites can help avail space for more floors due to its optimized floor to ceiling height benefits.
- In-house Manufacturing: Our in-house manufacturing capabilities ensure quality control, rapid prototyping, and efficient production schedules, guaranteeing timely delivery and adherence to project specifications.
- Comprehensive Support: Our dedicated Building Management System (BMS) support team provides end-to-end services including design consultation for system integration, installation & monitoring, to even ongoing maintenance/ troubleshooting, ensuring optimal performance and energy efficiency of your building systems.
- Facilitate CFD Analysis: We facilitate Computational Fluid Dynamics (CFD) analysis to optimize airflow and thermal comfort, ensuring design efficiency and compliance with environmental standards.
- Advanced Controls: Unlike most in the market, we embed the latest technology in our power modules and thermostats providing advanced digital options for precise monitoring and control of air distribution and quality.
- Industry leading Partnership: We are proud to partner with AirFixture (USA), renowned specialists and industry leaders in Underfloor Air Distribution (UFAD) systems. AirFixture brings decades of expertise and innovation to the table, providing cutting-edge solutions in the field. Their state-of-the-art products and services are integrated into our UFAD systems, guaranteeing top-quality performance and reliability.
- Feasibility Study and Conceptual Design: To get started, we assess your building’s suitability and develop initial plans for underfloor air vents and seamless system integration.
- Detailed Design and Engineering: We create detailed plans for airflow paths, specify suitable vent types, and outline underfloor requirements. Our team selects HVAC equipment that aligns with your needs and prepares comprehensive drawings and specifications. This guides efficient procurement and installation processes through detailed bidding.
- Delivery and Precision Installation: Once our material and systems are delivered at site, we strategically fit components according to design specifications, ensuring meticulous installation and seamless integration of UFAD systems.
- Commissioning and Testing: We ensure optimal system performance through rigorous airflow testing, control checks, and confirmation that all components meet our stringent design standards.
- Occupancy and Performance Monitoring: We monitor system performance post-installation, focusing on comfort, air quality, and energy efficiency. Adjustments to controls are based on real-world usage and client feedback.
Why Choose FLEXI?
Proven Expertise: As the leading provider of UFAD systems in India, we deliver solutions that are reliable, efficient, and adhere to the highest standards of performance and safety. Our partnership with AirFixture, which has over 20 years of industry experience, further enhances our ability to provide top-tier solutions you can trust.
Comprehensive UFAD Analysis & Solution: We provide thorough UFAD system support including detailed CFD analysis to ensure optimal airflow and thermal comfort.
Customer Satisfaction: Our UFAD systems ensure superior comfort and cooling, leading to higher productivity and customer satisfaction.
FAQs
UFAD systems deliver air at floor level, where pollutants tend to settle, minimizing the re-circulation of contaminants. This can lead to improved indoor air quality compared to traditional overhead systems.
-
- Underfloor plenum (height and space)
- Furniture layout and occupancy needs.
- Supply Air diffuser placement
- Return Air pathways
- Wall constructions
- AHU specifications
Compared to traditional HVAC systems, UFAD systems offer:
- Improved air quality due to better clean air stratification.
- Higher energy efficiency due to shorter duct runs and lower fan energy.
- Higher flexibility in architectural design due to its modular use with Raised Access Floor
- Higher comfort control due to the ability to customize climatic zones
- Better noise reduction due to lower velocity of air diffusion required
- Larger space savings as a result of the minimal ducting and area required for diffusion.
UFAD systems are particularly suitable for commercial buildings with open floor plans, high ceilings, or where flexibility in space utilization is desired. They can also be adapted for new constructions and rhetrofits.
UFAD systems contribute to sustainability goals by reducing energy consumption and improving indoor air quality. They can support green building certifications like LEED (Leadership in Energy and Environmental Design) by promoting energy efficiency and occupant comfort.
Yes, UFAD systems can be integrated with existing HVAC systems, often enhancing their performance. However, proper assessment and adjustment may be required to ensure compatibility and efficiency.
UFAD systems are generally low-maintenance. The underfloor plenum and diffusers are accessible for regular cleaning and adjustments. Proper maintenance ensures continued efficiency and performance.
Common misconceptions include the belief that UFAD systems are more complex or less effective than traditional systems. In reality, UFAD offers flexibility, improved comfort, and efficiency while being adaptable to various building needs.
The return air path is crucial for a well-designed low-pressure supply air plenum system. Properly designing the return air path ensures efficient warm air flow back to the Air Handling Unit (AHU), which maximizes occupant comfort and reduces costs. Overlooking or neglecting this aspect can lead to poor system performance and inefficiency.
Energy savings from UFAD systems depend on factors such as building design, climate, occupancy patterns, and HVAC equipment efficiency. Payback periods for initial investment can vary but are often influenced by long-term operational cost savings.
